REDARC 30AMP Solar Regulator

REDARC 30 Amp Solar Regulator: Efficient Power Management for Your Solar System

The REDARC 30 Amp Solar Regulator ensures optimal charging and power management for your solar setup. Designed to regulate solar energy and prevent overcharging, this reliable regulator maximizes the performance of your solar panel, extending battery life and ensuring efficient energy use. With a user-friendly design and robust build, it’s ideal for off-grid applications, overlanding, and camping. Whether you're powering up a battery or managing energy flow, the REDARC 30 Amp Solar Regulator offers precise control for reliable solar energy performance.

FEATURES

• Multi-stage charging- boost, absorption, and float
• Works with multiple battery types (REDARC Solar Remote Monitor required)
• Ideal for permanent installation or portable systems
• Multiple levels of protection – over temperature, over charge, reverse polarity
• Genuine  Industry Standard  Anderson™ SB™50 plug connection

SPECIFICATIONS

• Max. Power Voltage: 360/7520W
• Operating Temperature: −31°F to 131°F
• Weight: 1.2 lb (550 g)
• Height: 1.1" (28 mm)
• Width: 6" (153 mm)
• Depth | Length: 4.25" (108 mm)
• Warranty: 2 Years
• Connector Type: Anderson™ SB™ 50
• Input Voltage: 12V / 24V
• Max. Rated Output Current: 30A

IMPORTANT NOTES

• Battery default setting is AGM. The REDARC Solar Remote Monitor to change battery types and configuration settings is requited.
• Not compatible with Lithium (LiFePO4) batteries.

Product Manuals and Additional Information:

Solar Regulator Manual
